Elevate your power backup and off-grid systems with our ETL listed to UL 1741 Standards 48 Volt DC to 120/240 Volt AC inverter chargers, available for purchase on Appliance Guys. Experience unmatched efficiency with very little power loss, making them ideal for sustainability enthusiasts. This powerhouse provides up to 12,000 watts of continuous power and 36,000 watts of surge for 20 seconds, ensuring you're prepared for any power outage. Noteworthy features include a direct-connect terminal block, over-temperature protection, dual thermally-controlled fans, and marine-coated boards for durability.
Appliance Guys Exclusive Benefits:
- Lifetime Phone Support: Expert assistance always within reach.
- Open 7 Days a Week: Convenience tailored to your schedule.
- Price Match Guarantee: Shop confidently, knowing you're getting the best deals.
Features
Features
- ETL Listed to UL 1741 Standards: Ensures compliance with industry-leading safety and performance standards.
- Battery Priority Selector: Allows efficient management of power sources.
- AC Direct Connect Terminal Block: Facilitates easy connection, surpassing 8Kw or 12Kw capacity.
- Marine Coated and Protected: Resistant to humidity, airborne dust, and dirt for enhanced durability.
- Multi-Stage Smart Charger: 80 Amp capacity for GEL, Lead, AGM, and Lithium batteries.
- Three Cooling Fans: Thermal and load-based operation for optimal temperature control.
- Remote Panel Available: Offers convenient monitoring and control.
- Selectable 25W Power Save Mode: Efficient hibernation option for reduced power consumption.
- 4-Stage Battery Charger: Customizable charging for varied battery types.
- Two-Year Warranty: Backed by our commitment to quality and customer satisfaction.
Specifications
Output Specifications:
- Continuous Output Power: 8000 Watts
- Surge Rating: 24000 Watts (20 Seconds)
- Output Waveform: Pure Sine/Same as input (Bypass Mode)
- Nominal Efficiency: >88% (Peak)
- Line Mode Efficiency: >95%
- Output Frequency: 50Hz /- 0.3Hz / 60Hz /- 0.3Hz
- Typical Transfer Time: 10ms (Max)
- THD: < 7% under full linear load
- Ambient Operating Temperature: 14°F to 122°F (-10°C to 50°C)
Input Specifications:
- Nominal Input Voltage: 48.0Vdc
- Low Battery Alarm: 42.0Vdc-44.0Vdc
- Low Battery Trip: 40.0Vdc-42.0Vdc
- High Voltage Alarm: 64.0Vdc
- Low Battery Voltage Restart: 62.0Vdc
- Idle Consumption: 100 Watts
- Power Saver Mode Idle Consumption: <25 Watts
- Automatic Transfer Switch: 50A @ 220/230/240V
- Bypass: 50A @ 220/230/240V
Charger Specifications:
- Output Voltage: Depends on battery type
- Charger Rate: 80A
- Four-Stage Smart Charger with Current Adjust Dial: 20-100%
Dimensions & Weight
Dimensions & Weight
- Length: 23.3 inches
- Width: 16.3 inches
- Height: 7.9 inches
- Weight: 132 lbs
Shipping Dimensions & Weight:
- Length: 30 inches
- Width: 21.25 inches
- Height: 15.25 inches
- Weight: 176 lbs
